Nylon Filter Mesh-Can be customized Filter Mesh

Nylon filter mesh
Specification: JPP4-JPP200 (1950UM-5UM)
Basic Information

Materials: PA6, PA66
Color: Natural or white, or customized
Weave Type: Plain weave, Twill weave, Dutch weave
Width: 100cm, 127cm, 183cm, or customized
Product Form: Rolls.
Roll Length: 30-100m/Roll, Fixed Length, or customized

Specification Download

Multi bag filter housing and several bag filters in it.

Nylon filter mesh

Description

Macrokun’s Nylon Filter Mesh is made of monofilament PA6 or PA66 yarn/thread which is ideal for straining, sieving or filtering most liquids, powders or sludges; after weaving, Macrokun’s fabrics undergo a finishing process to add the properties required for specific applications. During the finishing process, the fabric is scoured to remove any foreign substances and the yarns are then stabilized within the weave in order to eliminate shrinkage by a process known as ‘heat setting’.

 We can make more than 10 types of processed nylon mesh products, such as nylon mesh filter discs, nylon mesh filter sheets,filter tubes, nylon mesh filter bags, nut & juice filter bags, etc. Customized products are accepted.

Hot Sale Product Image Price
5 Micron Nylon Filter Mesh 5 Micron Nylon Filter Mesh Contact us for a better price
15 Micron Nylon Filter Mesh 15 Micron Nylon Filter Mesh Contact us for a better price
25 Micron Nylon Filter Mesh Contact us for a better price
35 Micron Nylon Filter Mesh Contact us for a better price
40 Micron Nylon Filter Mesh Contact us for a better price
45 Micron Nylon Filter Mesh Contact us for a better price
50 Micron Nylon Filter Mesh Contact us for a better price
60 Micron Nylon Filter Mesh Contact us for a better price
70 Micron Nylon Filter Mesh Contact us for a better price
75 Micron Nylon Filter Mesh Contact us for a better price
90 Micron Nylon Filter Mesh Contact us for a better price
95 Micron Nylon Filter Mesh Contact us for a better price
100 Micron Nylon Filter Mesh Contact us for a better price
150 Micron Nylon Filter Mesh Contact us for a better price
200 Micron Nylon Filter Mesh Contact us for a better price
250 Micron Nylon Filter Mesh Contact us for a better price
300 Micron Nylon Filter Mesh Contact us for a better price
350 Micron Nylon Filter Mesh Contact us for a better price
400 Micron Nylon Filter Mesh Contact us for a better price

Advantages are:

1. They can be woven with great precision to give exact and regular apertures so the mesh openings are uniform,

2. Very smooth surface so that the filtered particles will easily separate from it,

3. They have great strength and elasticity Wear-resistant, Alkali-resistant,

4. Easy to clean and light in texture

Monofilament Nylon 6 or Nylon 6.6 Filter Mesh

Monofilament Nylon is a versatile material due to its great strength, flexibility, long life and resistance to abrasion. Nylon has excellent resistance to most common solvents and will operate continuously at temperatures up to 100°C in the chemical pH range 7-14. The term ‘Monofilament’ means that each thread used in the construction of the cloth is a single smooth solid strand instead of many smaller diameter threads twisted together, as in a spun or multifilament material. These monofilament threads are perfectly round in section and are extruded to very precise and uniform diameters.

Nylon Filter Mesh Application:

1. Collection of Cells and Algae

2. Particle Analysis

3. Large Particulate Filtration

4. Background Filter for automated particle imaging system

5. Pre-filtration of Solvents

6. Paint Monitoring

7. Medical Filtration (Blood Filtration)

Structures of air purifier and we can see the pre filter is made of nylon filter mesh.

Air purifier

Multi bag filter housing and several bag filters in it.

Water purification

A centrifugal sifters with basket type nylon filter mesh.

Centrifugal sifters

A man is inspecting the injector of car.

Injector filter

A France coffee cup and two coffee filter on white background.

Coffee filter

A layer of nylon test sieve with cover on black background.

Test sieve

A doctor is putting biopsy into biopsy bag.

Biopsy bage

A blood transfusion tubing filter is transfusing blood.

Blood tubing filter

For example : Mainly used in liquid filtration, powder filtration, petroleum, mining, pharmaceutical, chemical plant, paint, ink, oil product filtration, alcohol filtration, paint filtration, dye filtration, resin, monosodium glutamate, aquaculture, impurity filtration, food and other industrial screening and filtering.

Macrokun also can supply and offer

mesh filter bag

Structures of air purifier and we can see the pre filter is made of nylon filter mesh.

Hot or Cold Cut Mesh Parts

Multi bag filter housing and several bag filters in it.

Heat-sealed Mesh Filter Bags

A centrifugal sifters with basket type nylon filter mesh.

Welded Filter Tubes

A man is inspecting the injector of car.

Stamping Mesh Filter Elements

All Specification

Model Mesh count Thread Dia Mesh opening Thickness Weight
/ /cm /inch Micron Micron Micron (g/m2)
JPP4/1950 4 10 550 1950 1100 307
JPP5/1500 5 13 500 1500 1000 318
JPP6/1267 6 15 400 1267 800 244
JPP7/1079 7 18 350 1079 700 218
JPP8/900 8 20 350 900 700 249
JPP9/861 9 23 250 861 500 143
JPP9/811 9 23 300 811 600 206
JPP10/750 10 25 250 750 500 159
JPP10/700 10 25 300 700 600 229
JPP12/583 12 30 250 583 500 191
JPP12/533 12 30 300 533 600 274
JPP14/514 14 36 200 514 340 142
JPP16/425 16 40 200 425 340 160
JPP20/350 20 50 150 350 255 113
JPP20/300 20 50 200 300 340 200
JPP24/267 24 60 150 267 255 135
JPP28/237 28 70 120 237 204 101
JPP30/213 30 76 120 213 204 110
JPP32/213 32 80 100 213 170 80
JPP36/178 36 90 100 178 170 90
JPP40/150 40 100 100 150 170 100
JPP43/153 43 110 80 153 136 70
JPP48/128 48 120 80 128 136 77
JPP56/119 56 140 60 119 102 50
JPP64/96 64 160 60 96 102 58
JPP72/89 72 180 50 89 85 45
JPP80/75 80 200 50 75 85 50
JPP100/57 100 250 43 57 73 46
JPP110/48 110 280 43 48 73 52
JPP120/48 120 300 35 48 60 37
JPP120/40 120 300 43 40 73 55
JPP130/42 130 330 35 42 60 40
JPP130/34 130 330 43 34 73 61
JPP140/36 140 350 35 36 60 43
JPP157/25 157 400 43 25 73 74
JPP180/20 180 450 39 20 66 68
JPP200/15 200 500 39 15 66 76
JPP220/10 220 550 39 10 66 84
JPP240/5 240 600 39 5 66 91
